Slim Beam - Functional Trainer
Nohrd's SlimBeam is an exercise machine which features all the benefits of traditional cable machines, along with a top design, capable of blending into your home interior.
Enjoy the SlimBeam's slender shape, soft contours and high-quality wood, available in a broad range of shades and colours, to suit your tastes.
The SlimBeam is fixed at 10 cm from your wall and protrudes merely 20 cm in total into the room! It's base measures less than a half square meter!
The butterfly is the SlimBeam's main feature, allowing you to train on one or both sides. It can be swive led and set at any height. The fixtures adapter can hold a pull up or lat bar.
The adapter can also be set onto the front pole at any height. The pull-up bar is included with each SlimBeam purchase. It can be adjusted in height with the fixtures adapter.
14 weights at 5kg, plus the start weight at 5kg are elegantly housed in each SlimBeam.
The individual cable ratio (standard 3:1) permits various grades of weight. The cable machine´s range of motion is intrinsic! Extension length of up to 4 meters(double) or 8 meters (single, at 3:1 cable ratio) guarantee maximum functional expansion.
The maximal weight of 12.5 kg (single extension) or 25.0 (double extension) is distributed over 15 weight plates, delivering an extremely precise and harmonious weight gradation.
Extension 3:1 cable ratio kg 2:1 cable ratio kg 1:1 cable ratio kg
Single: 0,83 - 12,50 1,25 - 18, 75 2,50 - 37,50
Double: 1,65 - 25,00 2,50 - 37, 50 5,00 - 75,00
The cable ratio can be changed through the amount of rolls provided for use. The SlimBeam can be converted for this. A separate pulling cable is required.
Technical Details
TOTAL WEIGHT: 120KG
Standard cable ratio 3:1
Equipment included: Pull-up bar with adapter and cord.
14 weights: each 5 KG (Start Weight: 5KG)
Assembled Dimensions
Base plate: ø 44 cm
Height: 215 cm
Width: 40 cm
Depth: 20 cm
Distance to wall: 10 cm
